The Roadmachine takes our TCC Endurance vision further with big wheel capabilities, a dropped BB, adapted head tube angle, increased stack, and one of the industry’s smallest rear centers for a responsive ride.
Downtube Storage
We obsessed every detail of the downtube to optimally integrate internal, rattle-free storage and ensure compatibility with the 01’s Integrated Bottle Cage or any standard model. The removable pouch protects your essentials from the worst of the weather.
ICS2 Stem
The ICS2 stem is designed for complete stack and reach adjustability, allowing you to create the perfect position for your perfect ride. Bringing an incredibly low weight, high stiffness, stealth cable routing and further integration.
Fender Mounts
Our most winterproof bike is full-fender compatible, featuring mounting points on fork and frame for bolt-on fenders, plus BMC designed D-fender compatibility for the most simplified and lightweight approach to reducing road spray.
TCC Endurance
The Roadmachine takes our TCC Endurance vision further with big wheel capabilities, a dropped BB, adapted head tube angle, increased stack, and one of the industry’s smallest rear centers for a responsive ride.
SPECS
Frame
Roadmachine Carbon with Tuned Compliance Concept Endurance | Fender Mounts | Integrated Downtube Storage | Stealth Dropout Design | 12 x 142mm Thru-Axle
Fork
Roadmachine Carbon with Tuned Compliance Concept Endurance | Fender Mounts | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle
Stem
BMC ICS2 | Integrated Cockpit System Technology
Handlebar
BMC RAB 02 | Ergo Top Shape | Compact Bend
Seatpost
Roadmachine Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible
Saddle
Fizik Argo Tempo R5 | 150mm
Crankset
SHIMANO Ultegra (FC-R8100)
Chainrings
50-34T
Cassette
SHIMANO Ultegra (CS-R8101)
Cassette Size
11-34T
Chain
SHIMANO CN-M8100
Front Derailleur
SHIMANO Ultegra Di2 (FD-R8150)
Rear Derailleur
SHIMANO Ultegra Di2 (RD-R8150)
Shifters
SHIMANO Ultegra Di2 (ST-R8170)
Gears
2 x 12
Bottom Bracket
PF86 Bottom Bracket
Brake Levers / Calipers
SHIMANO Ultegra (BR-R8170)
Rotors
SHIMANO RT-MT800
Rotor Size (F/R)
160 / 140mm
Rims
XRD-522 | Tubeless Ready | 25 mm
Hubs (F/R)
XRD-522
Tires
Vittoria Rubino IV G2.0 | Tube only | 30mm
Tubeless Information
Tubeless Ready Rims | Tubetype Tires
Tire Clearance
up to "40mm measured" (frameset clearance) but limited to "34mm measured" by the front derailleur
Weight without Pedals
8.6 kg
ASTM Classification
Level 2
System Weight Limit
110kg
