Powerful and responsive
SyncDrive Pro motor with 85Nm of torque creates powerful pedaling assistance even at low speeds. Lightweight, stiff Advanced-grade composite frame with 140mm of Maestro rear suspension travel and 150mm up front delivers confident handling and control on rough trails.
Adaptable to the terrain
Flip chip feature lets you change the head tube and seat tube angles, along with the bottom bracket height, to fine-tune handling for varying trail conditions and individual riding style. You can choose the low position for fast, aggressive terrain, or high for a more XC-oriented rider position.
Clean cockpit
RideControl Go top tube integrated multi-function on/off button and RideControl Ergo 3 handlebar-mounted remote, which can be mounted on either grip, offer user-friendly controls and an uncluttered cockpit design.
SPECS
Motor
SyncDrive Pro, 85Nm, powered by Yamaha
Controller
RideControl GO integrated in TT, RideControl Ergo 3
Display
ANT+ cycle computer compatible
Battery
EnergyPak Smart 800, EnergyPak Plus range extender compatible
Colours
Gloss Carbon Smoke / Matte Carbon Smoke
Frame
Advanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system
Fork
Fox 36 Float Performance, 150mm travel, 44mm offset, Grip 3-position Micro Adjust damper, Boost 110x15QR, e-optimized
Shock
Fox DPS Performance, EVOL Large Volume sleeve, 3-position Lever, 185x52.5mm Trunnion mount, custom tuned
Handlebar
Giant Contact 35 Trail, 35x780mm
Grips
Giant Tactal Pro-E, single lock-on
Stem
Giant Contact SL 35
Seatpost
Giant Contact Switch, dropper, 30.9mm (S:125 / M:150 / L & XL:170)
Saddle
Giant Romero, Neutral
Pedals
Flatpedal
Shifters
Shimano Deore SLX
Front Derailleur
MRP HD2 co-moulded chain guide
Rear Derailleur
Shimano Deore SLX, 12-speed, Shadow+
Brakes
Shimano SLX, BR-M7120, 4-piston, hydraulic disc, 203mm
Brake Levers
Shimano SLX, I-spec EV
Cassette
Shimano CS-M6100, 10-51T, 12-speed
Chain
KMC e.12 Sport, NP/NP, e-bike optimized
Crankset
Praxis Wavetm 36T Cold Forged 4130 premium steel
Praxis e-Cadet+ custom forged crankarm set (S:160mm / M-L:165mm / XL:170mm)
Bottom Bracket
n/a
Rims
Giant AM 29", Tubeless ready, 30mm inner width, e-bike optimized
Hubs
Shimano MT410, Boost, Center-Lock
[F] 110x15mm / [R] 148x12mm Micro-Spline Drive Body Thru-axle
Spokes
Sapim E-Lite [R], Race [F], e-bike optimized
Tires
Front: Maxxis Minion DHF 29x2.6", Foldable, Tubeless, EXO+, 3C MaxxTerra
Rear: Maxxis Dissector 29x2.6", Foldable, Tubeless, EXO+, 3C MaxxTerra
Extras
Tubeless kit (liquid, valves, levers, manual, tool)
Inner tube supplied
Lighting
Optional: Giant Recon series e-bike lights available and direct connectable
Lock
Torx 25 Battery Lock with built-in Torque limiter
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Weight varies by size, finish, and accessories.
