Motor
SyncDrive Core, 50Nm, Powered by Yamaha
-
Controller
RideControl Dash
-
Display
RideControl Dash, full color lcd screen
-
Battery
EnergyPak 500, 36V 13.8Ah Rechargeable Lithium-Ion
-
Sizes
XS, S, M, L, (XS-S: 27.5, M-L: 29er)
-
Colours
Aged Denim
-
Frame
ALUXX aluminum, Overdrive 1½ - 1⅛" head tube, integrated KSA18 kickstand mount
-
Fork
SR Suntour XCM 32 ATB Coil, NLO, 29"/27.5", 100mm travel, Tapered 1½ - 1⅛" steerer (XS-S: 27.5", M-L: 29")
-
Shock
n/a
-
Handlebar
Giant Connect TR Riser 31.8x750mm (XS-S), 780mm (M-L)
-
Stem
Giant Contact
-
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
-
Saddle
Liv Sport
-
Pedals
Aluminum Platform
-
Shifters
Shimano Altus
-
Front Derailleur
n/a
-
Rear Derailleur
Shimano Alivio, M3100, 9-speed
-
Brakes
Tektro HD-M286, hydraulic disc, 180mm[F], 160mm[R]
-
Brake Levers
Tektro HD-M286
-
Cassette
Shimano CS-HG200, 11-36T
-
Chain
KMC e.9 Sport, e-bike optimized
-
Crankset
FSA Comet E-Bike crank arm setFSA MegaTooth Direct-mount 1X steel 36T
-
Rims
Liv, GX03V, 27.5 / 29, Alluminum(XS-S: 27.5, M-L: 29er)
-
Hubs
Giant eTracker Sport, [F] 9mm QR [R] 135mm QR
-
Spokes
Stainless steel
-
Tires
Maxxis Rekon 27.5x2.4" / 29 x 2.4" Wire Bead 60TPI (XS-S: 27.5, M-L: 29er)
-
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
