| Fork |
Sr Suntour XCT Coil w/Soft Spring and Preload, 80mm, 9x100mm QR |
| Rear Shifter |
Shimano SL-RV200-6R, 6sp, gripshift |
| Rear Derailleur |
Shimano TZ-500, 6sp, Direct mount |
| Crankset |
Alloy 3pc, 140mm, 28T Narrow Wide |
| Bottom Bracket |
Sealed Bearing , ST 68mm |
| Cassette |
Shimano MF-TZ500-6, 14T-28T, 6sp, Freewheel |
| Chain |
KMC Z6 |
| Front Brake |
C-Star, resin Pads, Mechanical Disc |
| Front Brake Rotor |
160mm, 6-Bolt |
| Rear Brake |
C-Star, resin Pads, Mechanical Disc |
| Rear Brake Rotor |
160mm, 6-Bolt |
| Handlebar |
Alloy Jr. Riser, 640mm, 30mm Rise |
| Stem |
Alloy 45mm Length, 31.8mm Clamp |
| Seatpost |
Norco Alloy 27.2mm, 250mm |
| Headset |
External Cup Ball Bearing, 1-1/8" EC 34 |
| Saddle |
Norco Jr XC, Steel Rail |
| Grips |
Norco Youth , 115mm Length |
| Front Hub |
Formula DC-1420, 9x100mm QR, 28h, 6-bolt |
| Rear Hub |
Formula XDS-2003, 9x135mm QR, Freewheel, 28h, 6-bolt |
| Rims |
Aluminum DW, 28h, 24" MTB |
| Front Tire |
CY Trail, 24x2.25, Wire |
| Rear Tire |
CY Trail, 24x2.25, Wire |
| Spokes/Nipples |
Stainless Steel, 14g |
