Frame
Specialized A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible
Seat Binder
Alloy, quick release, 34.9
Fork
RockShox Judy, Solo Air, Turnkey damper, 46mm offset, QR, 80/90/100mm travel (size-specific), steel steerer
Front Brake
Shimano BR-MT200, hydraulic disc ,180/160mm
Rear Brake
Shimano BR-MT200, hydraulic disc, 160 mm
Shift Levers
Shimano Deore, RapidFire Plus, 10-speed
Rear Derailleur
Shimano Deore, RD-M5120, 10-speed
Cassette
Sunrace, 11-46t, 10spd
Chain
KMC, X10, EPT anti-corrosion coating, 10-speed w/ Missing Link™
Crankset
Stout 1x, forged alloy
Bottom Bracket
Square-tapered, 73mm, internal bearings, 122.5mm spindle
Rims
Specialized Alloy, hookless, Tubeless ready, 25mm inner width
Front Hub
Formula DC-20, 6-Bolt, disc, 100x9mm spacing, quick-release
Rear Hub
Formula DC-22, 6-Bolt freehub, disc, 135x9mm spacing, quick-release
Spokes
Stainless, 14g
Front Tire
Fast Trak Sport, 650b/29x2.35"
Rear Tire
Inner Tubes
Standard 40mm PV 650B/29x1.75-2.4
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Handlebars
Specialized, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Grips
Specialized Trail Grips, lock-on
Saddle
Bridge Sport, Steel rails, 155/143mm
SeatPost
Alloy, 2-bolt clamp, 30.9mm
Weight
12.58 kg (27 lb, 11.7 oz)
Weight Size
MD
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
