| Frame |
Series 3 6061 Aluminum, 27.5 or 29" Wheels, 130mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs |
| Front Suspension |
X-Fusion Slide (29) or Sweep(27.5) Boost RC, 140mm Travel, Compression and Rebound Adjustment, 44mm Offset |
| Rear Suspension |
X-Fusion O2 Pro R, Custom Tune, 210x55mm, M8x25mm Hardware Top and Bottom |
| Rims |
Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible |
| Hub, Rear |
Shimano HB-MT200B, 141 QR, Centerlock, Standard Freehub Body |
| Hub, Front |
Shimano HF-MT400B, 110x15mm, Centerlock |
| Tires |
Vee Tire Snap WCE 2.35", Top 40 Compound, GXE Core, 90 TPI, Tubeless compatible |
| Derailleur, Rear |
Shimano RD-U6000, 11-Speed GS |
| Shift Lever |
Shimano, SL-U6000-11R, 11-Speed |
| Crankset |
Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, 170mm Crank Length, Boost Spacing |
| Chain |
Shimano LG-500 11-Speed |
| Brake, Front |
Tektro HD-M280 Hydraulic Disc, 180mm Rotor |
| Brake, Rear |
Tektro HD-M280 Hydraulic Disc, 180mm Rotor |
| Brake Levers |
Tektro HD-M280 |
| Handlebar |
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back |
| Stem |
Marin 3D Forged Alloy, 35mm |
| Grip |
Marin MTN, Closed End |
| Headset |
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2” |
| Seatpost |
X-Fusion Manic, 1x Composite Remote, Size XS-S 150mm Travel, Size M-XL 170mm Travel, 30.9mm |
| Saddle |
Marin Speed Concept |
