INNOVATION
PURE CYCLING MULTIPLIED BY X
Inspired by riders who enjoy long days in the saddle, the DOGMA X is about more than just performance; the bike has been engineered from the ground up to heighten the emotional experience of cycling and reshape how we think about endurance and speed.
It will redefine how we think about performance, offering real-world comfort.
CARBON T1100 1K
High tensile and high modulus carbon fiber with patented Nanoalloy Technology for extreme performances.
X STAYS
A new Pinarello technology capable of absorbing vibrations maintaining a light weight frame and a very reactive BB stiffness
ASYMMETRIC FRAME PINARELLO X
For first Pinarello understood that, while the thrust applied to both pedals is the same, the pull on the chain applies to the right side only. For this reason, all frames are optimized to compensate these unbalanced forces.
ENDURANCE GEOMETRY
A brand new approach that strikes the perfect balance between high-calibre performance and real-world comfort.
TYRE CLEARANCE UP TO 35MM
35mm tires to unlock the frames’ true potential in terms of both comfort and speed.
SPECS
FRAME: TorayCa T1100 1K Dream Carbon with Nanoalloy technology, internal cable routing, Italian BB, UCI approved
HANDLEBAR: MOST Jaguar XA TICR Alloy Aero Bar 42cm
STEM: MOST Tiger TICR Alloy Aero Stem 90mm
SEATPOST: Pinarello Aero seatpost with 3D printed titanium top seatclamp and bolts
SADDLE: Specialized Power Comp Saddle 155
PEDALS: N/A
SHIFTERS: Shimano Ultegra Di2 ST-R8170 / BR-R8170 Road Hydraulic Disc Brake Rear Flat Mount
Shimano Ultegra Di2 ST-R8170 / BR-R8170 Road Hydraulic Disc Brake Front Flat Mount
FRONT DERAILLEUR: Shimano FD-R8150 ULTEGRA DI2 FRONT DERAILLEUR
REAR DERAILLEUR: RD-R8150 ULTEGRA DI2 REAR DERAILLEUR
BRAKES: Shimano, RT-CL800, Rotor, 160mm, Center Lock, IRTCL800SI
Shimano, RT-CL800, Rotor, 140mm, Center Lock, IRTCL800SSI, IRTCL800SSI
BRAKE LEVERS: Shimano Ultegra Di2 ST-R8170 / BR-R8170 Road Hydraulic Disc Brake Rear Flat Mount
Shimano Ultegra Di2 ST-R8170 / BR-R8170 Road Hydraulic Disc Brake Front Flat Mount
BOTTOM BRACKET: Shimano BB-R9100, RIGHT & LEFT ADAPTER(ITALIAN), BEARING, W/TL-FC24, IND.PACK
CASSETTE: Shimano Ultegra CS-R8100 Cassette, Speed: 12, 11-34T, ICSR810012134
CHAIN: Shimano BICYCLE CHAIN, CN-M6100, DEORE, 126 LINKS FOR HG 12-SPEED, W/ QUICK-LINK
CRANKSET: FRONT CHAINWHEEL, FC-R8100, ULTEGRA, FOR REAR 12-SPEED, HOLLOWTECH 2, 170MM, 52-36T W/O CG, W/O BB PARTS
WHEELSET: ENVE 4.5 SES WHEELSET SHIMANO
TIRES: Pirelli, PZero Race TLR SL, Road Tire, Folding, Tubeless Ready, SmartEVO, TechWALL, 120TPI (BLACK) Black (700x28)
