LIGHTER WEIGHT
The lightweight ALUXX aluminum frame design provides a quick, agile ride feel. Featuring a new integrated head tube with fewer welds, giving it a sleek, carbon-like modern appearance while also keeping weight down.
POWERFUL
With the SyncDrive Sport 2 motor and removable 430Wh battery, this bike provides strong, consistent support wherever you ride. Need to go even farther? An optional 200Wh range extender is available for longer range.
INTELLIGENT
Packed with innovative features, the E-Lock system lets you lock the bike remotely via the App or control unit. Apple Find My compatibility locates your bike with your iPhone, sounds an alarm and sends alerts if the bike is moved, offering added peace of mind.
Motor
Giant SyncDrive Sport 2, 75Nm, PedalPlus 6-sensor technology
Controller
Giant RideControl Dash 2, Smart Assist automatic mode, 5 support levels, USB-C (10W)
Display
Giant RideControl Dash 2, high-angle visibility, full color LCD display
Battery
Giant EnergyPak Smart 430Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 200 range extender compatible
Charger
Giant EnergyPak smart charger 4A
Connectivity
Giant RideControl App enabled, ANT+ wireless display signal with e-bike profile
Sizes
XS, S, M, L (XS-S: 27.5, M-L: 29er)
Colours
Lunar Eclipse, Seafoam Green
Frame
ALUXX aluminum, Overdrive 1½ - 1⅛" head tube, integrated KSA40 kickstand mount
Fork
SR Suntour XCM ATB DS coil 29" 100mm travel 15x110 AH axle
Shock
n/a
Handlebar
Giant Connect TR Riser 31.8x690~750mm
Grips
Giant Sole-O Grip
Stem
Giant Contact
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Saddle
Liv Ergo Trail ESG
Pedals
Anti-slip Platform
Shifters
Shimano Cues
Rear Derailleur
Shimano Cues 9-speed
Brakes
Shimano MT200, hydraulic disc, 180mm [F/R]
Brake Levers
Shimano MT-200
Cassette
Shimano Cues, 11-41T, 9-speed
Chain
KMC eGlide NP/BK, e-bike optimized
Crankset
Forged allumin direct-mount chainring steel 36T, Forged alumium crank arms, (XS-S: 160mm, M-L: 165mm)
Bottom Bracket
-
Rims
Liv, GX03V, 27.5 / 29, Alluminum (XS-S: 27.5, M-L: 29)
Hubs
eTracker boost alloy 6-bolt disc 15x110mm [F] 12x148mm [R]
Spokes
Stainless steel
Tires
Maxxis Rekon Tanwall XS-S: 27.5x2.4" / M-L: 29 x 2.4" Wire Bead 60TPI
Lighting
-
Carrier
-
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
