Frame
ALUXX-grade aluminum, disc
-
Fork
Giant SXC32-3 RL, coil spring, 1.5" tapered alloy steerer, 15x110mm thru-axle, XS,S: 80mm (27.5), S, M, L: 100mm (29)
-
Shock
N/A
-
Handlebar
Giant Connect Trail, 31.8mm 27.5" XS: 690mm, S: 690mm 29" S: 750mm, M: 750mm, L: 750mm
-
Grips
Giant Sole-O
-
Stem
Giant Sport, 7-degree 27.5" XS: 40mm, S: 40mm 29" S: 40mm, M: 50mm, L: 50
-
Seatpost
Giant Sport, 30.9mm 27.5" XS:100x350mm, S: 100x350mm 29" S: 100x350mm, M:100x375mm, L : 100x375mm
-
Saddle
Contact Ergo
-
Pedals
MTB caged
-
Shifters
Microshift, Advent 1x9, SL-M9295R
-
Front Derailleur
N/A
-
Rear Derailleur
Microshift, Advent 1x9, RD-M6195M with clutch
-
Brakes
Tektro HDC TKD 149, hydraulic, Tektro rotors [F]180mm, [R]160mm
-
Brake Levers
Tektro TKD 149, for small hands
-
Cassette
Microshift, CS-H093, 11-46
-
Chain
KMC X9
-
Crankset
ProWheel Charm, steel, 52.5mm chainline 32t (27.5") & 30t (29") 27.5" XS: 165mm, S: 165mm 29" S: 170mm, M: 170mm, L: 170mm
-
Bottom Bracket
cartridge
-
Rims
27.5": Giant GX03V 27.5", alloy, double wall, 21mm inner width 29": Giant GX03V 29", alloy, double wall, 21mm inner width
-
Hubs
alloy, sealed bearing
-
Spokes
stainless, 14g
-
Tires
Maxxis Recon Race 27.5x2.4" or 29x2.4", 60tpi wire bead
-
Extras
2.4" max tire size, max chainring 32T
-
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
