GRAVEL CRUSHER
For those who like their gravel riding fast and free, this lightweight composite flyer lets you choose your objective: Pin on a number and go for the win, or chart a weekend adventure and discover how far you can go. With its composite frame, adjustable wheelbase, and internal storage to carry your essentials, the Revolt Advanced is ready for anything.
FAST AND VERSATILE
An Advanced-grade composite frame and fork combine for lightweight efficiency and smooth control. A two-position flip chip on the rear dropout lets you adjust the wheelbase: short for quicker handling, or long for added tire clearance (up to 53mm) and improved stability. You can use the included D-Fuse seatpost* for more flex and compliance, or switch to a traditional 30.9mm round seatpost or dropper post.
TUNED COMPLIANCE
Dropped seatstays with small-diameter tubing absorb road shocks and vibrations on all types of gravel. The Contact SL XR D-Fuse alloy handlebar and carbon D-Fuse seatpost help smooth out rough tracks, improving control and minimizing fatigue over long distances.
SMART INTEGRATION
Internally routed cables offer clean, uncluttered cockpit aesthetics and improved aero performance. An easily accessed storage compartment inside the top tube lets you securely carry tools, snacks and other essentials. And additional integrated mounts on the top tube, fork and rear dropout make it easy to modify with additional packs or fenders. All-new, molded, chainstay and down tube protection help defend the frame against impacts and quell noise.
Highlights
With a new composite frameset featuring fully integrated cable housing, this lively gravel bike helps you push your limits on variable terrain. The D-Fuse seatpost and handlebar absorb shocks and vibrations, giving you greater control and less fatigue. A flip chip on the all-new, full composite rear dropout adjusts wheelbase and tire clearance, and you can choose the included D-Fuse seatpost for maximum compliance or a 30.9mm round seatpost or dropper post. Details include a new internal storage compartment on the down tube and additional frame mounts to add bottle cages, racks and other accessories.
-
Frame
Advanced-grade composite, 12x142mm thru-axle, disc, flip chip dropout, down tube storage
-
Fork
Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc, flat mount disc
-
Handlebar
Giant Contact XR D-Fuse, 31.8mm
XS, S:42cm, M, M/L:44cm, L, XL:46cm
-
Grips
Stratus Lite 3.0
-
Stem
Giant Contact AeroLight, -10 degree
-
Seatpost
Giant D-Fuse, composite, 14mm offset
-
Saddle
Giant Grit *some bikes may be substituted: Giant Approach
-
Shifters
Shimano GRX RX610, 2x12
-
Front Derailleur
Shimano GRX RX820
-
Rear Derailleur
Shimano GRX RX820
-
Brakes
Shimano GRX RX400 hydraulic, Giant MPH rotors [F]160mm, [R]160mm
-
Brake Levers
Shimano GRX RX610
-
Cassette
Shimano CS-HG710, 12-speed, 11x36
-
Chain
KMC X12L-1
-
Crankset
FSA Omega Modular AGX+, 32/48 XS, S:170mm, M, M/L:172.5mm, L, XL:175mm
-
Bottom Bracket
FSA BB-AL86, press fit
-
Rims
Giant P-X2 Disc wheelset, alloy
-
Hubs
Giant alloy, 12mm thru-axle
-
Spokes
Sapim
-
Tires
Giant Crosscut Grip, tubeless, 700x45c *some bikes may be substituted: Maxxis Rambler, tubeless, 700x40c
-
Extras
tubeless prepared, 53mm max tire size in "long" flip chip position, 45mm max tire size in "short" flip chip position, integrated down tube storage bag
-
Max Tire Clearance
53mm
-
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
