Durable and stable for a sturdy ride you can trust.
A forged bottom bracket yoke adds strength, more tire clearance, and stiffness. A tapered head tube for an integrated headset improves handling and stability.
A smooth, refined look.
Custom hydroformed aluminum frame tubing with smooth welding adds a sleek look.
Supportive, progressive design for uncompromised performance.
A low standover top tube design, modern trail geometry with a 65-degree headtube angle, and short 435 stays make this bike a solid choice for anyone when heading out on your favourite trails.
Premium frame features.
Thruaxle dropouts front and rear, and internal cable routing through the frame protects from wear and adds to the clean look and feel.
No Other Way Limited Lifetime Warranty.
Charger's frame design, hardware and component decisions have been made specifically to keep it on the trail for longer. Accidents can happen, and when they do, our No Other Way Limited Lifetime Guarantee is our promise to get you back on the trail as soon as possible.
| Frame |
Aluminum, Smooth Welding, 12x148mm Boost, Tapered HT |
| Fork |
X-fusion RC32 Air, 130mm, 15x110mm Boost |
| Rear Shifter |
Shimano Deore SL-M6200-R, 12spd |
| Rear Derailleur |
Shimano Deore RD-M6200, SGS, 12spd |
| Crankset |
Prowheel Alloy, 30T, 170mm (S-M), 175mm (L - XXL) |
| Bottom Bracket |
Prowheel Cartridge |
| Cassette |
Shimano Deore CS-M6200-12, 10-51T, 12sp |
| Chain |
KMC 12spd |
| Front Brake |
Shimano Deore BR-MT200, Resin pads |
| Front Brake Rotor |
Shimano SM-RT26, 160mm, 6-bolt |
| Rear Brake |
Shimano Deore BR-MT200, Resin pads |
| Rear Brake Rotor |
Shimano SM-RT26, 160mm, 6-bolt |
| Brake Levers |
Shimano Deore BL-MT200 |
| Handlebar |
Norco Aluminum, 760mm (S), 780mm (M,L,XL, XXL) 30mm Rise |
| Stem |
Alloy 40mm Length, 31.8mm Clamp |
| Seatpost |
X-Fusion Manic LC, 31.6mm, 130mm (S), 150mm (M), 170mm (L/XL/XXL) |
| Headset |
Sealed Cartridge Bearings, Tapered 1-1/8" - 1.5" ( IS42/28.6 | IS52/40 ) |
| Headset Spacer |
3x10mm |
| Saddle |
Norco XC, Steel Rail |
| Grips |
Norco lock-On, 130mm length |
| Pedals |
Nylon Flat Pedal, Chromoly Axle |
| Seatpost Clamp |
Norco Alloy QR, 34.9mm ID |
| Front Hub |
KT Sealed Bearing, 15x110mm Boost, 32h, 6-bolt |
| Rear Hub |
KT,12x148mm Boost, MS, 32h, 6-bolt |
| Rims |
Alloy XD-155, 32H |
| Front Tire |
Maxxis Forekaster, 29x2.4" (27.5X2.25"size S), Wire |
| Rear Tire |
Maxxis Forekaster, 29x2.4" (27.5X2.25"size S), Wire |
| Spokes/Nipples |
Stainless Steel, 14g |
