Chunky rock gardens, roots and technical climbs. This hard-charging trail bike adapts to the terrain, giving you confidence and control on all types of singletrack.
29er confidence and control
29-inch wheels optimized to roll over technical terrain with balance and stability, giving you more momentum on tricky climbs and confidence to fly on fast singletrack descents. Added clearance for up to 2.5-inch tires.
Progressive suspension
Maestro rear suspension features a trunnion mount shock with a longer stroke and smoother feel. With 135mm of full rear-wheel travel (and 150mm up front), it features an Advanced Forged Composite upper rocker arm for increased stiffness and strength plus lower overall frame weight.
Adjustable geometry
A flip chip lets you change the headtube and seattube angles, along with the bottom bracket height, to fine-tune the handling. You can choose the low position (65.5/77.2 head/seattube angle and 40mm BB drop) for fast, open terrain, or high (66.2/77.9 head/seattube angle and 30mm drop) for slower, tighter singletrack.
SPECS
Sizes:
S, M, L, XL
Colours:
Metallic Black / Black
Frame:
ALUXX SL-Grade Aluminum front and rear triangles, 135mm Maestro suspension, flip chip, 12x148mm thru-axle
Fork:
RockShox 35 Gold RL, 150mm travel, 44mm offset, 15x110 Maxle Stealth, custom tuned for Giant
Shock:
Fox Float DPS Performance, 185x55mm, custom tuned for Giant
Handlebar:
Giant Contact TR35, 780mm width, 35mm clamp, 20mm rise
Grips:
Giant Tactal Pro Single Lock-On
Stem:
Giant Contact SL 35
-
S: 40mm
-
M: 40mm
-
L: 50mm
-
XL: 50mm
Seatpost:
Giant Contact Switch Dropper, remote
-
S: 125mm travel / 30.9 x 395mm
-
M: 150mm travel / 30.9 x 440mm
-
L: 170mm travel / 30.9 x 450mm
-
XL: 170mm travel / 30.9 x 450mm
Saddle:
Giant Romero
Pedals:
N/A
Shifters:
SRAM SX Eagle, 1x12
Front Derailleur:
N/A
Rear Derailleur:
SRAM SX Eagle
Brakes:
Shimano BR-MT420, hydraulic disc
-
Rotors: Shimano RT-56
-
Front: 203mm
-
Rear: 180mm
SPECS
Brake Levers:
Shimano BL-MT401
Some bikes may be substituted with:
Tektro HD-M745 Orion
Cassette:
SRAM SX, 11–50t
Chain:
SRAM SX Eagle
Crankset:
SRAM SX, 30T
Bottom Bracket:
SRAM DUB, press-fit
Rims:
Giant AM 29, alloy
Hubs:
-
Front: Alloy, Boost 15x110mm, loose bearing
-
Rear: Alloy, Boost 12x148mm, sealed bearing
Spokes:
Sapim
Tires:
-
Front: Maxxis Minion DHF, 29x2.5" WT, EXO, TR
-
Rear: Maxxis Dissector, 29x2.4" WT, 60 TPI, 3C Max Terra, EXO, TR
Extras:
Tubeless prepared, 2.5" max tire size, 34T max chainring size
Weight:
Weight varies by size, finish, and components. For accurate measurement, consult your local dealer. All Giant bikes are engineered for best-in-class weight and ride quality.
