Motor
SyncDrive Sport 2, 75Nm, powered by Yamaha
-
Controller
RideControl Dash
-
Display
RideControl Dash, full color lcd screen
-
Battery
EnergyPak Smart 500, EnergyPak Plus 250Wh range extender compatible
-
Sizes
XS, S, M, L, (XS: 27.5" / S, M, L: 29")
-
Colours
Cosmos Navy
-
Frame
ALUXX SL-grade aluminum, 125mm travel FlexPoint suspension system, 148x12 rear axle, Universal Derrailleur hanger, 184x44 shock, 1.5~1.8" headset
-
Fork
SR Suntour XCR 34 LO-R, 140mm travel, tapered steerer, Lockout, 110x15 thru-axle
-
Shock
SR Suntour Raidon R, 190x45mm, custom tuned
-
Handlebar
Giant Connect TR Riser 31.8x750mm (XS-S), 780mm (M-L)
-
Grips
Liv Tactal Pro Single Lock-On Grips
-
Stem
Giant Contact
-
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
-
Saddle
Liv sylvia E
-
Pedals
N/A
-
Shifters
Shimano Deore LinkGlide
-
Front Derailleur
MRP HD2 co-moulded chain guide
-
Rear Derailleur
Shimano Deore LinkGlide, 10-speed
-
Brakes
Tektro HD-M745 Orion, 4-piston, hydraulic disc, 203mm
-
Brake Levers
Tektro HD-M745 Orion
-
Cassette
Shimano CS-LG400-10, 11-43T, 10-speed LinkGlide
-
Chain
Shimano, LinkGlide, CN-LG500
-
Crankset
FSA Comet E-Bike crank arm setFSA MegaTooth Direct-mount 1X steel 36T
-
Bottom Bracket
n/a
-
Rims
AM30, 27.5" (XS), 29"(S, M, L), Tubeless ready, 30mm inner width
-
Hubs
Giant eTracker Boost, [F] 110x15 [R] 148x12mm
-
Spokes
Stainless Steel
-
Tires
Maxxis Minion DHF 27x2.5"(XS), 29X2.50"(S, M, L) Foldable, TLR, EXO, 60TPI [F]Maxxis Dissector 27.5x2.4"(XS), 29X2.40"(S, M, L) Foldable WT, TLR, EXO, 60TPI [R]
-
Extras
-
-
Lighting
-
-
Lock
Torx 25 Battery Lock with built-in Torque limiter
-
Carrier
-
-
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
